| Settings | ES920 | ES520 | ES120 | ES60 |
|---|---|---|---|---|
| Image |  |  |  |  |
| SKU | ES920 | ES520 | ES120 | ES60 |
| Price | 80,000.00฿ – 86,950.00฿ | 65,000.00฿ – 70,650.00฿ | 34,500.00฿ – 37,500.00฿ | 21,000.00฿ – 26,500.00฿ |
| Stock | ||||
| Add to cart | เลือกรูปแบบ This product has multiple variants. The options may be chosen on the product page | เลือกรูปแบบ This product has multiple variants. The options may be chosen on the product page | เลือกรูปแบบ This product has multiple variants. The options may be chosen on the product page | เลือกรูปแบบ This product has multiple variants. The options may be chosen on the product page |
| Weight | 17 | 14.5 | 12 | 14.5 |
| Dimensions | 37.5 × 134 × 14.5 เซนติเมตร | 37.5 × 134 × 14.5 เซนติเมตร | 37 × 145 × 26.5 เซนติเมตร | 37.5 × 134 × 14.5 เซนติเมตร |
| White key surfaces | ||||
| Black key surfaces | ||||
| Action | ||||
| Hammers | ||||
| Soundboard | ||||
| Agraffes | ||||
| Duplex scaling | ||||
| Back posts | ||||
| Pedals | • F-10H pedal unit Damper (with half-pedal support) | • F-10H pedal unit Damper (with half-pedal support) | F-1SP switch pedal Damper (with half-pedal support) Soft Sostenuto | Compatible with F-10H damper pedal Damper (on/off) • F-10H pedal unit |
| Casters | ||||
| Lid props | ||||
| Softfall | ||||
| Position | ||||
| Hard Finish | ||||
| Lock | ||||
| Other features | Bluetooth Audio recording, Overdubbing | |||
| Cutoff bar | ||||
| Keyboard | Responsive Hammer III action • 88 keys • Counterweights • Grade-weighted hammers • Ivory Touch white key surfaces • Let-off simulation • Triple sensor key detection | Responsive Hammer Compact II action • 88 keys • Grade-weighted hammers • Matte key surfaces • Triple sensor hammer detection | Responsive Hammer Compact action • 88 keys • Grade-weighted hammers • Matte key surfaces | Responsive Hammer Lite action • 88 keys • Grade-weighted hammers • Matte key surfaces |
| Speaking length | ||||
| Piano Sound | Harmonic Imaging XL (HI-XL) • 88-key stereo sampling • SK-EX; SK-5; EX recording 256 note maximum polyphony | Progressive Harmonic Imaging (PHI) SK-EX; EX recording • 88-key stereo sampling 192 note maximum polyphony | Harmonic Imaging (HI) SK-EX EX K-60 recording • 88-key stereo sampling 192 note maximum polyphony | Stereo sampling Harmonic Imaging (HI) • SK-EX recording 192 note maximum polyphony |
| Piano Resonance | Acoustic Rendering • Damper Resonance • String Resonance • Undamped String Resonance • Cabinet Resonance | • Damper Resonance • String Resonance | • Damper Resonance • String Resonance | |
| Accessories Others | ||||
| Type | ||||
| App Functions | PiaBookPlayer (iOS/Android) PianoRemote (iOS/Android) | PiaBookPlayer (iOS/Android) PianoRemote (iOS/Android) | PiaBookPlayer (iOS/Android) PianoRemote (iOS/Android) | |
| Available Finishes | Black (ES920B) White (ES920W) | Black (ES520B) White (ES520W) | Black (ES120B) Light Grey (ES120LG) White (ES120W) | Black (ES60B) |
| Basic Functions | 4-band EQ faders Dual Four Hands Registration Split Startup Setting Transpose Tuning | Dual Four Hands Registration Split Startup Setting Transpose Tuning | Dual Registration (4 memories) Speakers On/Off Split Startup Setting Transpose Tuning | Dual Speakers On/Off Split Transpose Tuning Speaker EQ |
| Bench | ||||
| Bluetooth * | Bluetooth (Ver. 4.1; GATT compatible) Bluetooth Audio with aptX support Bluetooth Low Energy MIDI Specification compliant | Bluetooth (Ver. 4.1; GATT compatible) Bluetooth Audio with aptX support Bluetooth Low Energy MIDI Specification compliant | Bluetooth (Ver. 5.0; GATT compatible) Bluetooth Audio (Ver. 5.1; A2DP compatible) Bluetooth Low Energy MIDI Specification compliant | |
| Brilliance | Yes | Yes | Yes | |
| Colour/Finish | ||||
| Concert Magic | ||||
| Display | 128 x 64 pixel OLED | 128 x 64 pixel OLED | ||
| Drum Rhythms | Rhythm Section • 100 styles (x 2 variations) • 4-part accompaniment select • 100 preset chord sequences • Chord mode: Full Keyboard 1 Finger Preset • 'On Bass' chord detection | 100 patterns | 100 patterns | 30 patterns |
| Headphone | 2 x 1/4" Stereo jacks | 2 x 1/4" Stereo jacks | 1 x 1/4", 1 x 1/8" Stereo jacks | 1 x 1/4" Stereo jack |
| Headphone Enhancements | Headphone Type Spatial Headphone Sound | Headphone Type Spatial Headphone Sound | ||
| Headphones | ||||
| Key Cover | ||||
| Lesson Songs | 377 pieces (via PiaBookPlayer app), 9 books | |||
| Line In | 1 x 1/8" Stereo [unbalanced] | 1 x 1/8" Stereo [unbalanced] | ||
| Line Out | 1/4" L/MONO; R [unbalanced] | 1/4" L/MONO; R [unbalanced] | n/a | 1/4" L/MONO; R [unbalanced] |
| MIDI | MIDI IN, MIDI OUT | MIDI IN, MIDI OUT | Bluetooth MIDI *, USB-MIDI | USB-MIDI |
| Music Rest | detachable type (included), Transparent | detachable type (included), Transparent | detachable type (included) | detachable type (included) |
| No. of Songs | 10 songs | 3 songs | 3 songs | |
| No. of Sounds | 38 voices | 34 voices | 25 voices | 17 voices |
| Other details | ||||
| Other Effects | 16 types + amp simulator (3 types) | 16 types + amp simulator (3 types) | Preset (can be disabled) | Preset (can be disabled) |
| Other Functions | ||||
| Others | Damper (for F-10H) Damper/Soft/Sostenuto (for F-302 or GFP-3) Speakers on/off switch | Damper (for F-10H) Damper/Soft/Sostenuto (for F-302 or GFP-3) Speakers on/off switch | Damper (for F-1SP F-10H) Pedal (for GFP-3 F-351) | Damper (for F-1SP F-10H) |
| Output Power | 40 W (20 W x 2) | 40 W (20 W x 2) | 20 W (10 W × 2) | 20 W (10 W × 2) |
| Parts | 2 parts | 1 part | 1 part | |
| Piano Adjustment | Virtual Technician (21 parameters) • Cabinet Resonance • Damper Noise • Damper Resonance • Decay Time • Fall-back Noise • Half-Pedal Adjust • Hammer Delay • Hammer Noise • Key Volume (incl. 88-key User Key Volume) • Key-off Effect • Minimum Touch • Release Time • Soft Pedal Depth • Stretch Tuning (incl. 88-key User Tuning) • String Resonance • Temperament (incl. User Temperament) • Temperament Key • Topboard Simulation • Touch Curve (incl. User Touch Curve) • Undamped String Resonance • Voicing (incl. 88-key User Voicing) | Virtual Technician (17 parameters) • Damper Noise • Damper Resonance • Decay Time • Fall-back Noise • Half-Pedal Adjust • Hammer Delay • Key Volume (incl. 88-key User Key Volume) • Key-off Effect • Minimum Touch • Soft Pedal Depth • Stretch Tuning (incl. 88-key User Tuning) • String Resonance • Temperament (incl. User Temperament) • Temperament Key • Touch Curve (incl. User Touch Curve) • Voicing (incl. 88-key User Voicing) • Topboard | Virtual Technician (17 parameters) • Touch Curve • Voicing • Damper Noise • Damper Resonance • Decay Time • Fall-back Noise • Half-Pedal Adjust • Hammer Delay • Key-off Effect • Minimum Touch • Release Time • Soft Pedal Depth • String Resonance • Temperament Key • Topboard Simulation • Stretch Tuning • Temperament | Virtual Technician (1 parameters) • Touch Curve |
| Piano Music | ||||
| Power | AC adaptor (PS-154) Power cable | AC adaptor (PS-154) Power cable | AC adaptor (PS-129) Power cable | AC adaptor (PS-129) Power cable |
| Power Consumption | 18 W | 18 W | 9 W | 7 W |
| Record/Playback | KSO, MP3, SMF, WAV | KSO [Kawai song format], SMF (Playback only) | ||
| Reverb | 6 types | 6 types | 6 types | 3 types |
| Sheet Music | ||||
| Sound Demo | 2 Rhythm Section demo songs 25 sound demo songs 5 Main demo songs | 23 sound demo songs | 16 sound demo songs | 15 sound demo songs |
| Speakers | (8 x 12) cm x 2 | (8 x 12) cm x 2 | 12 cm x 2 | 12 cm x 2 (full range speakers) |
| Supported models | ||||
| Time Signatures | 1/4; 2/4; 3/4; 4/4; 5/4; 3/8; 6/8; 7/8; 9/8; 12/8 | 1/4; 2/4; 3/4; 4/; 5/4; 3/8; 6/8 | 1/4; 2/4; 3/4; 4/; 5/4; 3/8; 6/8 | 1/4; 2/4; 3/4; 4/; 5/4; 3/8; 6/8 |
| Total Memory | approximately 90,000 notes | approximately 5,000 notes | approximately 15,000 notes | |
| USB to Device | Yes | Yes | ||
| USB to Host | Yes | Yes | Yes |
